Centrifugal Pump PP Series

centrifugal-pump

Our Mechanical Seal Pumps come with a variety of seal option And flexibility. Our pump offering provides smooth even flow, Which is advantageous in applications where problems have Risen or could due to pulsation caused by Pump.

Centrifugal Pump PP Series

Request Quote

INTRODUCTION

Over year of experience, in 1988 Precision Engineering Company' is one of the leading suppliers of chemical process pumps which supply these pumps worldwide. These pumps are used in wide range of process applications. They are highly reliable and offer low operating costs in the process industry. All ranges of efficient chemical process pumps are designed as per the technical standards. 'Precision' is globally operating leading manufacturer of innovative non-metallic pumps for handling aggressive, abrasive and chemically contaminated fluids and fluid mixtures. Our mission at 'Precision Pump' is to provide high quality products utilizing vision and insight to exceed our customers' expectations. We are committed to provide our quality products at very competitive prices and at minimum lead-time. We will continue to deliver excellence, strive for continues improvement and further increase our presence in the Global markets.

These Pumps are provided with injection molded wetted parts as well as Super alloys& industrial graded Casting & fabrication and have a robust construction. The materials used are (SS- 304/304L, SS - 316/316L, SS - 904/904L, MONEL/TITANIUM, Alloy - 20, Aluminum, C.S, M.S. Hastalloy B/C, Rubber Lining, PP, PTFE, PVDF) etc. the material of construction is specially selected depending on the specific application. This ensures of highest corrosion resistance and stability. The shaft sleeve & Mechanical Shaft Seals are selected to suit the service condition, for Pumps handling fluids containing suspended particles slurry etc. and for effluent services especially seal with suitable faces are available with proper environment control arrangements. PEC series pumps along with the above functions are ideal for heavy duty application. These pumps have a back Pull out Design Construction for easy Maintenance without disturbing the Piping & have a special Feature of Oil Bathing Body System for a Continuous & Long Fife Running Pumps.

APPLICATION

'Precision' application engineers provide a valuable resource to our customers. Their goal is to match process problems with the best and most cost effective pump and sealing solutions. We can often provide information based on prior experience that is industry and application specific to our customers' specific applications. With our product range, we are covering a wide range of pumping applications involving acids, alkalis, chemically contaminated, corrosive and solids-carrying fluids in many market segments. Main applications of our pumps include the chemical process industry, the environmental sector, the metallurgical and surface finishing industries, flue gas clean-up and applications with similar requirements.

Sea water desalination

PCB Manufacture

Fertilizer production

Wastewater treatment

Solar cell manufacturing

Chlor-alkali electrolysis

Exhaust air scrubbers

Electroplating

Ore extraction

Biogas treatment

Glass finishing

Copper electrolysis

Ultra-pure water

Coating lines

Acid regeneration

Process water

Chemical plant manufacturing

Nickel electrolysis

Manufacturing of bio fuels

Acid production

Steel pickling

Performance Data

Pump Capacity: up to 280 m3/h
Total differential Head: up to 60 mtrs.
Operating Temperature (t): up to 80oC

PTFE Bellow

PTFE: bellows provide universal chemical resistance for wide services & non-wetted metal parts eliminate the need for expensive metallurgies. TB/TBR seal is inherently hydraulically balanced to ensure proper face loading. Installs easily on outside of stuffing box; eliminates the use of elastomers.

Gland Packing

Gland packing pumps come with pure PTFE or PTFE Impregnated Blue Asbestos against specific customer requirements. *standard pump fitted with GFT/CER Teflon Bellow Mechanical seal Shaft Sleeve. Shaft Sleeve of different material depending on the compatibility of the liquid to be handled.

Mission & Vision

Precision' has envisioned to be recognized as a trusted partner in pump solutions. Precision wants to offer its customers one stop solution to their fluid handling requirements. A precision pump has a vision to become an alternative offer to an expensive and monopolize brand of products. Our mission at Precision Engineering Company is to provide high quality products utilizing vision and insight to exceed our customers' expectations. We are committed to provide our quality products at very competitive prices and at minimum lead-time. We will continue to deliver excellence, strive for continues improvement and further increase our presence in the Global markets. As pump professionals, we recognize that meeting our customers' needs by providing quality products and value added services, so that we remain a dependable and cost effective source, is key to both our and our customers' success.

Quality Policy

We are acted to supply best quality products as per customers' requirements. We believe our customers deserve best quality products for their money and we will continue to deliver excellence, strive for continuous improvement and further increase our presence in the global markets.

PUMP SPECIFICATION

Pump Model PEC H.P IMP SPE Head in Mtrs.
SUC DIS IMP Capacity in M3/Hr.
PEC - 10 32 25 130 1 115 Mtrs. 15 11 9 7
M3/Hr. 1 4 8 8
PEC - 20 40 25 150 2 140 Mtrs. 25 20 15 10
M3/Hr. 1.5 5 7.5 12
PEC - 30 40 25 150 3 160 Mtrs. 32 30 25 15
M3/Hr. 1 5 9 14
PEC - 40 50 32 180 5 160 Mtrs. 32 24 19 10
M3/Hr. 2 10 17 22
PEC - 50 80 50 200 7.5 180 Mtrs. 35 30 25 25
M3/Hr. 10 18 26 30
PEC - 60 80 50 200 10 190 Mtrs. 45 37 30 25
M3/Hr. 5 20 30 35
PEC - 70 80 50 230 15 220 Mtrs. 60 50 45 40
M3/Hr. 20 30 40 45
